    Black Marine Usb Panel Mount Keyboard With Optical Trackball

    Ask Lasest Price
    Brand Name : IKB-MKB
    Model Number : K-TEK-M380-OTB-FN-BL-BT
    Certification : CE, FCC, ROHS, IP65, IP68, ISO 9001-2015
    Price : USD/PC
    Payment Terms : Full payment in advance, Western Union, T/T, Paypal
    Supply Ability : 3000psc/month
    Delivery Time : ASAP Within 2 weeks upon payment confirmed
    • Product Details
    • Company Profile

    Black Marine Usb Panel Mount Keyboard With Optical Trackball


    Black Marine Usb Panel Mount Keyboard With Optical Trackball


    DIMENSIONS: 380.0mm x 129.5mm (top panel)


    DESCRIPTION: 85 keys IP65 dynamic vandal proof industrial and military keyboard with adjustable industrial backlight and IP68 dynamic washable 38mm stainless steel optical trackball module with 800 DPI resolutions for fast and accurate cursor position, with FN (F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12) on the top line for easy operation, with industrial PCB with carbon-on-gold key switch technology with key stroke 1.50mm with extremely good tactile feeling for fast and accurate input without any noise, red clean key lock/disable the keyboard for easy cleaning and washing without needing to take out the keyboard from PC, rear panel mounted. Black titanium electroplated included.


    MAIN FEATURES:


    1. NVIS-compliant adjustable blue backlight, while NVIS backlighting makes this keyboard ideal for military, aviation or vehicle night applications.


    2. Strong polymer keys ensure the keyboard’s resistance to willful destruction, vandal-proof, against corrosion, weather-proof under harsh environments.


    3. IP65 waterproof execution according to degree of protection IP65 from the panel, the keyboard is sealed against the ingress or liquid and dirt, when mounted in a suitable enclosure.


    4.Ease of customizing with multiple languages, to accommodate any foreign language layout.


    5. PS/2, USB connection output cables that plug directly into the host computer for normal keyboard operations.


    6. Operational life of more than 10 million cycles per key.


    7. Resistant to most commonly used cleaning agents.


    8.Integral 38mm PS2/USB compatible IP65 Mechanical trackball /IP65 chameleon backlight trackball/IP68 optical trackball/IP68 laser trackball module with left, middle & right mouse keys.



    RELIABILITY

    RoHS, CE and FCC, ESD
    Protection Level: IP65 (front panel)
    Vandal resistant IK10
    Key Lifespan >10 million actuations
    MTBF >50000H
    MTTR <30min

    ELECTRICAL DATA


    Supply Voltage: +5V DC +/-5%
    Current Rating:
    40mA for keyboard and trackball without backlight.
    240mA for keyboard and trackball with backlight on.
    EMC Standard: It is compliance with the council IEC 61000-4-2:2008

    ;IEC 61000-4-3:2006+AI:2007+A2:2010;IEC 61000-4-4:2004

    EMI: EN 55022: 2010

    EMS: EN 55024:2010
    Lifespan>5 years
    Switch Contact Material: Carbon-on-Gold key switch technology PCB.
    Interface: PS2, USB available.
    OS: All windows, Linux, Unix, Mac OSX

    ENVIRONMENTAL ADAPTABILITY
    Operating temperature:-20oC to +60oC
    Storage temperature: -30oC to +70oC
    Operating RH: 100%
    Atmospheric pressure: 60-106Kpa.
    Saline mist: 96 hours, IEC 60512-6
    Damp heat test at + 40oC: 21 days, IEC 60512-6
    Dry heat test at + 85oC: 10 days, IEC 60512-6

    ENVIRONMENTAL ADAPTABILITYY

    Operating temperature:-20oC to +60oC
    Storage temperature: -30oC to +70oC
    Operating RH: 100%
    Atmospheric pressure: 60-106Kpa.
    Saline mist: 96 hours, IEC 60512-6
    Damp heat test at + 40oC: 21 days, IEC 60512-6
    Dry heat test at + 85oC: 10 days, IEC 60512-6


    Actual Pictures:

    Mechanical Drawing:
