    Mini Short Stroke Membrane Industrial Keypad White Color


    Mini Short Stroke Industrial Membrane keyboard with white color

    DESCRIPTION: 28 keys compact format IP65 dynamic membrane industrial keypad with industrial metal dome PCB electronics controller protected and shielded by stainless steel housing, industrial metal dome PCB with gold-on-gold metal dome key switch technology with short stroke 0.45mm with extremely good tactile feeling for reliable data input, surface mounted extremely flush with anti-microbial functionalities, the fonts printed on the film underneath will never fade, durable and scratch-proof polyester withstand to most chemicals and liquids under the harshest environments, ruggedized aluminum plate with sand blasting & oxygenation treatment, with top panel mounted solution.
    DIMENSIONS: 159.0mm x 104.0mm (top panel)


    MECHANICAL DATA
    Number of keys28 keys
    Key switch Technologymetal dome PCB with gold-on-gold metal dome key switch technology with short stroke keys
    Actuation Force3.5N±0.2N (press point)
    Key Travel0.45±0.05mm
    Mounting TypeTop panel mounting
    Colors2 (white, black)
    G.W.0.50KGs
    Switch lifemore than 1 million of operations
    Key Dimensions (print area)14.0mm x 14.0mm
    ELECTRICAL DATA
    Supply VoltageDC +5V±5%
    Current Rating30mA
    EMC StandardEN 55032:2015 EN 55035:2017
    Lifespan> 5 years
    InterfacePS2, USB available
    OSAll Windows, Linux, Unix, Mac OSX, Vxworks, Android, (U-cos--To be confirmed).
    ENVIRONMENTAL ADAPTABILITY
    Operating temperature-20℃ to +65℃
    Storage temperature-30℃ to +75℃
    Saline mist96h, IEC60512-6
    Damp heat test at +40℃21 days, IEC 60512-6
    Dry heat test at +85℃10 days, IEC 60512-6
    Humidity100%
    Atmospheric pressure60-106Kpa
    RELIABILITY
    RoHS , CE, FCC
    Protection LevelIP65 dynamic (front panel)
    Key Lifespan>1 million actuations
    MTBF>20000H
    MTTR<30min
    APPLICATIONSIndustrial, marine, food and beverage, processing factory, medical and pharmaceutical, numerical control machine etc.
