    Industrial Metal Kiosk Compact Keyboard with Ruggedized Trackball

    Ask Lasest Price
    Brand Name : IKB-MKB
    Model Number : K-TEK-A300-TB-FN
    Certification : CE, FCC, ROHS, IP65, IP68, ISO 9001-2015
    Price : To be quoted
    Payment Terms : Full payment in advance, Western Union, T/T, Paypal
    Supply Ability : 3000psc/month
    Delivery Time : ASAP Within 2 weeks upon payment confirmed
    • Product Details
    • Company Profile

    Industrial Metal Kiosk Compact Keyboard with Ruggedized Trackball


    Mini 81 keys IP65 static waterproof industrial trackball keyboard with FN keys


    Quick Detail:

    • Stainless steel keyboard
    • Waterproof, dust-proof and vandal resistant
    • CE,FCC,ROHS,IP65 certificate
    • USB or PS/2 interface
    • Customized layout

    Special Features:

    1. function keys F1, F2..F10, F11, F12 are on the top panel for easy operation


    2. 3 mouse buttons designed for right & left clicking and scrolling up and down with ball rolling


    3. rear panel mounting solution.


    4. 2 optional washable 25mm stainless steel trackball:
    ----IP65 static 400DPI mechanical trackball module,
    ----IP68 dynamic washable 800DPI optical trackball module


    5. one complete silicone rubber under the top stainless steel plate for easy mounting & sealing tightly with cabinet


    6. Ease of customizing with multiple languages, to accommodate foreign or custom variants.


    7. Easily mounting into enclosure or panel, and is provided with PS/2, USB connection output cables that plug directly into the host computer for normal keyboard operations.


    ELECTRICAL DATA :

    Supply Voltage:+5V DC +/-5%
    Current Rating:appr. 20mA
    Emission:EN 50081-1
    Immunity:EN 50082-1
    Lifespan> 5 years
    Switch Contact Material:Carbon-on-Gold key switch technology PCB.
    Interface:PS2, USB available.
    OS:DOS/Windows95/98/NT/ME/2000/2003/XP/Vista/Win7, Linux, Unix, Mac OSX

    ENVIRONMENTAL ADAPTABILITY :


    Operating temperature:-20oC to +60oC
    Storage temperature:-30oC to +70oC
    Operating RH:30-90%
    Atmospheric pressure:60-106Kpa.
    Saline mist:96 hours, IEC 60512-6
    Damp heat test at +40oC:21 days, IEC 60512-6
    Dry heat test at +85oC:10 days, IEC 60512-6

    RELIABILITY:

    • RoHS Compliant, CE and FCC
    • Protection Level: IP65(front panel)
    • Vandal resistant IK09
    • Key Lifespan >10 million actuations
    • MTBF >50000H
    • MTTR <30min

    Application: Used for date input of Kiosks, Industrial platform, Banking, Medical, Gas pumping, Gaming machine and Security equipment.


    Front View


    Back View
