    Small IP65 dustproof and waterproof panel mount keyboard with 103 keys

    Ask Lasest Price
    Certification : CE, FCC, ROHS, IP65, IP68, ISO 9001-2015
    Delivery Time : ASAP Within 2 weeks upon payment confirmed
    Payment Terms : Full payment in advance, Western Union, T/T, Paypal
    Supply Ability : 3000psc/month
    Brand Name : IKB-MKB
    Model Number : K-TEK-M398KP-FN-BL
    • Product Details
    • Company Profile

    Small IP65 dustproof and waterproof panel mount keyboard with 103 keys


    Small IP65 dustproof and waterproof panel mount keyboard with 103 keys


    Special Features:


    1. Custom layout with multi languages

    2. 103 keys IP65 industrial & military keyboard with adjustable industrial backlight
    3. 1.50mm key stroke is with extremely good tactile feeling for fast and accurate input without any noise
    4. The keyboard with Fn keys on the top line and numeric keypad on the right side.
    5. rear panel mounted with mounting holes on the both sides.
    6. With firm tactile perception for comfortable operation
    7. Ease of customizing with multiple languages, to accommodate foreign or custom variants.


    Specifications:


    MECHANICAL DATA

    Key top style

    Protuberant rectangular keys.

    Actuator/keys materials

    polymer

    Top SS plate

    1.5mm stainless steel plate with super quality durable Black Titanium Electroplated

    Back SS plate

    1.5mm stainless steel plate

    Robust polycarbonate frame

    Between top SS plate and back SS plate for fixing and mounting keys & gold PCB electronics controller, with mounting holes along the keyboard mounting edge for fixing keyboard with rear panel mounting.

    Key Size

    11.4mm x 11.4mm for normal keys,
    11.4mm x 24.3mm for enter key,
    11.4mm x 71.8mm for space bar.

    Switch life

    more than 10 million of operations.

    Lettering

    laser-etched or high quality ink print.


    ELECTRICAL DATA

    Supply Voltage

    +5V DC +/-5%

    Current Rating

    30mA for keyboard without backlight.
    150mA for keyboard with backlight on.


    EMC Standard:

    It is compliance with the council IEC 61000-4-2:2008;IEC 61000-4-3:2006+AI:2007+A2:2010;IEC 61000-4-4:2004

    EMI:

    EN 55022: 2010

    EMS:

    EN 55024:2010

    Switch Contact Material:

    Carbon-on-Gold key switch technology PCB.

    Interface:

    PS2, USB available.

    OS:

    All windows, Linux, Unix, Mac OSX


    ENVIRONMENTAL ADAPTABILITY

    Operating temperature

    -20oC to +60oC

    Storage temperature

    -30oC to +70oC

    Operating RH

    100%

    Atmospheric pressure

    60-106Kpa

    Saline mist

    96 hours, IEC 60512-6

    Damp heat test at + 40oC

    21 days, IEC 60512-6

    Dry heat test at + 85oC

    10 days, IEC 60512-6


    RELIABILITY

    Certification

    RoHS Compliant, CE and FCC,IP65,ESD

    Vandal resistant

    IK10

    Key Lifespan

    >10 million actuations

    MTBF

    >50000H

    MTTR

    <30min


    Quality Small IP65 dustproof and waterproof panel mount keyboard with 103 keys for sale
