    Backlight EMC Keyboard Military Level Silicone Rubber Keyboard 88 Keys USB Interface

    Ask Lasest Price
    Brand Name : IKB-MKB
    Model Number : K-TEK-M315TP-FN-MS-BL-NV-151B
    Certification : CE, FCC, ROHS, IP65, IP68, ISO 9001-2015
    Price : To be quoted
    Payment Terms : Full payment in advance, Western Union, T/T, Paypal
    Supply Ability : 3000psc/month
    Delivery Time : ASAP Within 2-3 weeks upon payment confirmed
    • Product Details
    • Company Profile

    Backlight EMC Keyboard Military Level Silicone Rubber Keyboard 88 Keys USB Interface


    Backlight EMC Keyboard Silicone Rubber Military Level Keyboard


    DESCRIPTION: 88 keys IP67 dynamic sealed & ruggedized silicone rubber military level keyboard with sealed and tough touch pad for fast and accurate cursor position, 12 FN keys (F1, F2...F11, F12) are on top line for easy operation, membrane key switch technology with long stroke (1.20mm) with extremely good tactile feeling for fast and accurate data input without any noise and error output, without missing keys or repeat output, with durable coating & anti-microbial keyboard surface withstand to most chemicals and liquids under harsh environment, FN + Clean combination key for easy cleaning via lock/disable whole keyboard without needing to take away the keyboard from PC, rear panel mount with super thin ruggedized aluminum back plate with mounting holes, adjustable industrial white backlight included. USB interface, designed to meet MIL-STD-461G and 810F, wide temperature -40 to +60°C. with strong anti-interferance, stability and anti radiation
    DIMENSIONS : 315.0mm x 108.0mm (L x W)
    MECHANICAL DATA
    Keys:88 keys
    Key top style:
    Protuberant rectangular keys with tactile feeling.
    Touch pad
    Lifespan: over 5 millions actuation
    Mutual capacitance sensing:
    X/Y axis location detection resolution: 40 Counts /mm
    X/Y position report: relative
    Mouse tracking speed: > 1.016 m/s
    Key travel:1.2mm
    Supply voltage
    5V ± 0.25V
    G.W.:0.80KGs
    Dimensions:315.0mm x 108.0mm (L x W)
    ELECTRICAL DATA
    Supply Voltage:+5V DC +/-5%
    Current Rating: appr.
    appr. 50mA (non-backlight), 250mA (with backlight on)
    EMC Standard:EN 55032:2015 EN 55035:2017
    Lifespan> 5 years
    Switch Contact Material:
    appr. 50mA (non-backlight), 250mA (with backlight on)
    Interface:USB
    Cable length:
    Standard 0.8/1.0m, customized length available.
    OS:All Windows, Linux, Unix, Mac OSX, Vxworks, Android, (U-cos--To be confirmed)
    ENVIRONMENTAL ADAPTABILITY
    Operating temperature:-40oC to +60oC
    Storage temperature:-45oC to +65oC
    Operating RH:100%
    Atmospheric pressure:60-106Kpa.
    Saline mist:96 hours, IEC 60512-6
    Damp heat test at + 40oC:21 days, IEC 60512-6
    Dry heat test at + 85oC:10 days, IEC 60512-6
    RELIABILITY
    RoHS, CE and FCC
    Protection Level:IP67
    Key Lifespan>5 million actuation
    MTBF>20000H
    MTTR< 30min




    EMC KEYBOARD MAIN FEATURE:
    Keyboard with white adjustable backlighting, which makes this keyboard ideal for applications where night vision goggles are necessary.
    Keyboard provides full-size versatility in a rugged, compact design, rugged construction for reliable functionality
    The keyboard lacks the crevices found between the keys of a regular keyboard, which is protected against dust, dirt, grease and corrosive liquids, which means it can withstand direct hose water, disinfectants, environmental contaminants and heavy industrial use.
    Special durable-coating for excellent mechanical and chemical resistance
    FN + Clean key
    -Prevents data from being sent while the keyboard is wiped down, allowing user to clean at any interval with minimal downtime
    -User is notified of ‘lock down mode’ by brightly lit FN+CLEAN KEY
    With firm tactile key feel, key travel 1.2mm key travel.
    Actuation Force: 1.2N±0.1N
    Ease of customizing with multiple languages, to accommodate foreign or custom variants.
    USB connection cable that plugs directly into computer like keyboard operations, without needing any driver.
    Enclosure: industrial silicone, aluminum back plate
    Key life: 5 millions
