    2 Keys Rugged Industrial Touchpad Silicone Rubber Waterproof Pointing Device IP65

    Ask Lasest Price
    Brand Name : IKB-MKB
    Model Number : K-TEK-M90TP-IL-SS
    Certification : CE, FCC, ROHS, IP65, IP68, ISO 9001-2015
    Payment Terms : Full payment in advance, Western Union, T/T, Paypal
    Supply Ability : 3000psc/month
    Delivery Time : ASAP Within 2 weeks upon payment confirmed
    Price : To be quoted
    • Product Details
    • Company Profile

    2 Keys Rugged Industrial Touchpad Silicone Rubber Waterproof Pointing Device IP65

    IP65 Rugged Silicone Touchpad Industrial Waterproof Pointing Device


    DESCRIPTION: IP65 dynamic Sealed and Ruggedized Rubber Touchpad for fast and accurate cursor position, with 2 raised

    mouse buttons under touchpad, with stainless steel housing protects the electronics controller, with mounting
    holes along the rear panel mounting plate for rear panel mounting.
    MAIN FEATURES:
    -IP65 dynamic Sealed and Ruggedized Touchpad for fast and accurate cursor position
    -Special dura-coating for excellent mechanical and chemical resistance
    -With firm tactile key feel, key travel 1.5mm.
    -Enclosure: industrial silicone
    -Ease of customizing with multiple languages, to accommodate foreign or custom variants.
    -PS/2, USB connection cables that plug directly into computer like keyboard operations.
    MECHANICAL DATA:
    Keys:2 keys
    Key top styleProtuberant rectangular keys with tactile feeling
    Touchpad Cover:Composite Mutual Capacitance sensing
    Switch life:More than 5 million of operations
    X/Y Position Resolution:1000 points/inch(40 points/mm)(graphics tablet mode)
    Validated touch width:40.33mm (max)
    Validated touch length:56.14mm (max)
    Output (self-detectable depending on cable):PS2 or USB
    Cable Length:2.0m
    G.W.:0.50KGs

    ELECTRICAL DATA :
    Supply Voltage:+5V DC +/-5%
    Current Rating:17 mA
    EMC Standard:EN 55032 : 2015 , EN 55035: 2017
    Lifespan> 5 years
    Switch Contact Material:Carbon-on-Gold key switch technology with gold PCB
    Interface:PS2, USB available
    OS:All Windows, Linux, Unix, Mac OSX, Vxworks, Android, (U-cos--To be confirmed)

    ENVIRONMENTAL ADAPTABILITY :
    Operating temperature:-20 to +60
    Storage temperature:-30 to +70
    Humidity:5%--95%
    Atmospheric pressure:60-106Kpa

    RELIABILITY:
    RoHS, CE and FCC
    Protection Level: IP65
    Key Lifespan >5 million actuations
    MTBF >20000H
    MTTR <30min

    APPLICATIONS:

    • MEDICAL: lab, hospital, clinic, dental, such as carts, diagnostic equipments, operation rooms, dialysis centers etc;
    • MATERIAL HANDLING: mobile keyboard, data entry, assembly line etc
    • MILITARY: Army, Navy, Air force
    • INDUSTRIAL: Industrial automation, pharmaceutical, oil and gas, food and beverage, clean or dirty manufacturing environments, warehouses
    • OTHER INDUSTRIES

    DIMENSIONS : 90.0mm x 90.0mm (front panel)

    ACTUAL PHOTOS:





    ------------------------------------------- Our Certifications: -------------------------------------------------------



    ------------------------------------------------------Company Tour ----------------------------------------------------



    FAQ

    Q1) Are you factory ?
    A:Yes ! Key Technology (China) Limited is a professional manufacture in Rugged keyboards for more than 14 years. Our Innovative design and superior quality make Key Technology popular all over the world.


    Q2) Can you customize the surface and program of your product according to my requirements?
    A:Yes. You need to provide the surface draft !


    Q3) Is your keyboard waterproof ?
    A:We do have waterproof metal keyboards with degree IP65-IP68.


    Q4) Can you do a sample for me?
    A: Yes, we can make you a sample for your approval.
