    800DPI IP68 Stainless Steel Joystick Keyboard With Trackball Mouse

    Ask Lasest Price
    Brand Name : IKB-MKB
    Model Number : K-TEK-A443-38-OTB-JS-FN-DT-DWP
    Certification : CE, FCC, ROHS, IP65, IP68, ISO 9001-2015
    Price : To be quoted
    Payment Terms : Full payment in advance, Western Union, T/T, Paypal
    Supply Ability : 3000psc/month
    Delivery Time : ASAP Within 2 weeks upon payment confirmed
    • Product Details
    • Company Profile

    800DPI IP68 Stainless Steel Joystick Keyboard With Trackball Mouse

    83 Keys IP68 Stainless Steel Keyboard with Joystick Trackball Mouse

    MODEL NO.: K-TEK-A443-38-OTB-JS-FN-DT-DWP
    DESCRIPTION:
    1.83 Keys Compact Format IP68 dynamic Vandal Proof Stainless steel industrial keyboard with joystick.Joystick has the mouse function
    2.With IP68 dynamic rated 38.0mm harden resin optical trackball (stainless steel optical trackball is optional).
    3.Trackball module with 800DPI resolutions for fast and accurate cursor position with extremely smooth operation without any noise
    4.With 3 mouse buttons above the trackball for easily direct cursor.
    5.Function keys F1, F2..F10, F11, F12 are on the top line for easy operation.
    6.Industrial PCB with carbon-on-gold key switch technology with long stroke (2.0mm) for fast and accurate data input.
    7.Movable stand alone DESK TOP VERSION.
    8. It is good for outdoor application with direct rain and very harsh environments with humidity, much dynamic water, oil, dirt, salt mist etc.
    APPLICATION :
    -Unsupervised or semi-supervised positions of varied access applications.
    -Internet terminals and information kiosks at universities, shopping malls, hotels, banks, airports, railway-stations.
    -Other public areas, ticket vending machines, gas stations, cash machines (ATMs/CDM), Internet public phones etc.
    MECHANICAL DATA:
    Actuator/keys:83 keys, super quality SUS304 brushed stainless steel
    Key top style:
    Protuberant rectangular keys, laser engraved & etched legends & raised braille on keys are available
    Key Size:14.0mm x 14.0mm for normal keys, 14.0mm x 28.0mm for enter key, 14.0mm x 70.0mm for space bar.
    Key travel:2.0mm long stroke.
    Actuation Force:1.2N+/-0.1N for key 14.0mm x 14.0mm , 2N+/-0.1Nfor key 14.0mm x 28.0mm
    Switch life:more than 5 million of operations.
    Stainless Steel Housing:super quality brushed stainless steel
    G.W.:3.00KGs

    ELECTRICAL DATA :
    Supply Voltage:+5V DC +/-5%
    Current Rating:appr. 20mA
    EMC Standard:EN 55032:2015 EN 55035:2017
    Lifespan> 5 years
    Switch Contact Material:Carbon-on-Gold key switch technology PCB.
    Interface:PS2, USB available.
    OS:All Windows, Linux, Unix, Mac OSX, Vxworks, Android

    DIMENSIONS: 443.0mm x 145.0mm (L x W )

    ENVIRONMENTAL ADAPTABILITY
    Operating temperature: -20 to +60
    Storage temperature: -30 to +70
    Operating RH: 30-90%
    Atmospheric pressure: 60-106Kpa.
    Saline mist: 96 hours, IEC 60512-6
    Damp heat test at + 40oC: 21 days, IEC 60512-6
    Dry heat test at + 85oC: 10 days, IEC 60512-6
    RELIABILITY :
    RoHS Compliant, CE and FCC, ESD
    Protection Level: IP68
    Vandal resistant IK08
    Key Lifespan >5 million actuations
    MTBF >20000H
    MTTR <30min
